The product dimensions are only the starting point. A treadmill needs room to arrive, unfold, operate, cool, and move out of the way without turning the room into an obstacle course.
Measure the operating footprint first
Use the fully open dimensions from the product page or manual. Mark the outline on the floor with removable tape. Then stand where the treadmill controls and deck will be and check doors, drawers, chairs, and walking routes around it.
Add clear space around the machine
Follow the exact clearance guidance in the model manual. Do not place the rear of the treadmill against a wall or block ventilation. Keep children, pets, cords, curtains, and loose objects out of the operating area.
Check the storage position separately
Foldable does not mean invisible. Measure the folded height, width, and depth, along with the space needed to raise or lower the deck. If the product has transport wheels, confirm that the floor and route are suitable for moving its full weight.
Trace the delivery route
- Door and hallway width
- Stair turns and landings
- Elevator dimensions
- Ceiling height at the final location
- Space to open the package and remove protective material
Think about the floor
The surface should be level, stable, and suitable for the model. Check the manual before using a mat or placing a treadmill on carpet. Protect the floor without blocking ventilation or allowing the frame to rock.
Choose for the room you will use
A compact model can make daily walking easier in a shared room. A larger foldable treadmill may offer more walking-and-running range but still needs a dedicated operating zone. Measure before comparing features so the room helps the routine instead of fighting it.
Apollo 11 dimensions and weight: all eight models
Dimensions below are length × width × height in inches. Machine net weight excludes packaging; shipping gross weight includes packaging. Specifications checked September 5, 2026.
| Model | Product / unfolded (in) | Folded (in) | Package (in) | Machine net (lb) | Shipping gross (lb) |
|---|---|---|---|---|---|
| Apollo 11 Elite | 43.6 × 20.6 × 7.9 | — | 46.9 × 23 × 8.7 | 51.4 | 58.4 |
| Apollo 11 Vibe | 41.6 × 20.2 × 7.1 | — | 44.9 × 21.5 × 7.9 | 40 | 52.7 |
| Apollo 11 Ultra | 47.8 × 24.4 × 9.3 | — | 52.6 × 27 × 10.5 | 86 | 97.9 |
| Apollo 11 Max | 48 × 25 × 7.7 | — | 52 × 27.6 × 8.7 | 75 | 86 |
| Apollo 11 Pro | 60 × 28.4 × 50.6 | 60 × 28.4 × 9.4 | 63.4 × 30 × 9.5 | 114.9 | 133.2 |
| Apollo 11 Pro+ | 60 × 28.4 × 50.6 | 60 × 28.4 × 9.4 | 63.4 × 30 × 9.5 | 114.9 | 133.2 |
| Apollo 11 Ultimate | 53.9 × 29.5 × 46.9 | 53.9 × 29.5 × 9.5 | 58.6 × 30.3 × 10.6 | 105.2 | 122.1 |
| Apollo 11 Ultimate+ | 53.9 × 29.5 × 46.9 | 53.9 × 29.5 × 9.5 | 58.6 × 30.3 × 10.6 | 105.2 | 122.1 |
For walking pads, “—” means no separate folded dimensions are listed here. Product dimensions are not running-belt dimensions and do not include the safety clearance required during use. Consult the exact model manual before installation.
Pro and Pro+ share the listed dimensions and weights; Ultimate and Ultimate+ also share the listed dimensions and weights. Vibe machine net weight is 40 lb.
Measure storage and delivery separately
A Vibe measures 41.6 × 20.2 × 7.1 inches, but its package measures 44.9 × 21.5 × 7.9 inches. Check both your storage space and the delivery route. A folded Pro or Pro+ is 9.4 inches high; Ultimate and Ultimate+ are 9.5 inches high. Allow extra room to move the machine without scraping furniture, and follow the manual for permitted storage positions.
Measure doorways, turns and stairs against package dimensions before delivery. Plan handling using shipping gross weight, and use machine net weight when considering relocation after unpacking. The product footprint alone is not the full space needed for safe operation; follow your model’s clearance instructions.
